Automatic Multi

Basic Info.

Model NO.	JZH-1200
Glue Capacity	10L
Power	380V / 50Hz
Speed	1500-1800 (Pieces/Hours)
Transport Package	Wooden Case
Specification	4315X2230X2600mm
Trademark	Jinjiu
Origin	China
Production Capacity	1500-1800pieces/Hours

Product Description

JZH1200 Automatic Multi-functional Box Folding Machine

USEAGE:

In addition to making traditional boxes, machine can also make other palletizing boxes, as well as the folding packaging boxes without glue, it is suitable for food packaging boxes; fruit/vegetable packaging boxes and other product boxes and etc.

PERFORMANCE HIGHLIGHTS:

1. Imported glue spraying system,with automatic glue spraying compensation function;
2. Add the folding knives device, can do various boxes
3. cardboard adopt automatic feeding with bottom suction, continuous feeding, forming, conveying and stacking at one time;
4. Adopt PLC controller, photoelectric tracking system, gas source detection system, human-Machine interface, automate the whole process of box forming
5. Fiber positioning for folding and gluing to reduce gluing errors. Servo pushes the cardboard with glue on front and back to reduce photoelectric eyes error, which can make glue more accurate.
6. Infrared safety protection system to ensure the safety of personnel operation;
7. Automatic fault diagnosis function;
8. Quick mold change adjustment device;
9. Cage design of machine frame, integral processing, grouping combination;
10. The whole machine occupies a small area and has good stability.

TECHNICAL PARAMETERS:

Thickness of cardboard	Min. size	1.5mm
	Max. Size	5mm
Power		380V/50Hz
Noise		≤80dB
Speed		1200-3000pcs/hour
Cardboard stacking height		280mm
Stacked weight		30kg
Total power		About 15kw
Glue capacity		10L
Air source		50 Litre/min
Machine weight		2500kg
Dimensions		2750*1550*25005mm(L*W*H)

PACKAGING BOXES SPECIFICATIONS:

Package Size	W: Min. size	370mm
	W: Max. size	1000mm
	L: Min. Size	500mm
	L: Max. size	1000mm
Carton sizeLength=LWidth=WHight=HHight= K(cover)	L: Min. Size	180mm
	L: Max. size	520mm
	W: Min. Size	180mm
	W: Max. size	380mm
	H: Min. Size	60mm
	H: Max. size	230mm

Box Samples:
